Skylicht::CAreaLight Class Reference

This object holds the parameters for area lights. More...

#include <Lighting/CAreaLight.h>

Inheritance diagram for Skylicht::CAreaLight:

Public Member Functions
virtual void	initComponent ()
virtual void	updateComponent ()
virtual void	endUpdate ()
virtual CObjectSerializable *	createSerializable ()
virtual void	loadSerializable (CObjectSerializable *object)
virtual void	setRenderLightType (ERenderLightType type)
void	setSize (float x, float y)
float	getSizeX ()
float	getSizeY ()
bool	needRenderShadowDepth ()
void	beginRenderShadowDepth ()
void	endRenderShadowDepth ()
core::vector3df	getPosition ()
const core::matrix4 &	getWorldTransform ()
const core::aabbox3df &	getWorldBounds ()
Public Member Functions inherited from Skylicht::CLight
const SColorf &	getColor ()
void	setColor (const SColorf &c)
float	getAttenuation ()
float	getRadius ()
core::aabbox3df	getBBBox ()
ERenderLightType	getRenderLightType ()
int	getLightTypeId ()
void	setBounce (u32 b)
u32	getBounce ()
void	setRadius (float r)
void	setSpotAngle (float angle)
float	getSplotCutoff ()
void	setSpotInnerAngle (float angle)
float	getSpotInnerCutof ()
void	setSpotExponent (float e)
float	getSpotExponent ()
core::vector3df &	getDirection ()
bool	isCastShadow ()
void	setShadow (bool shadow)
bool	isDynamicShadow ()
void	setDynamicShadow (bool shadow)
void	setIntensity (float f)
float	getIntensity ()
u32	getLightLayers ()
void	setLightLayers (u32 layers)
bool	isAffectingDefaultObjects ()
void	setLightPriority (u32 priority)
u32	getLightPriority ()
void	validate ()
ITexture *	getShadowTexture ()
void	setShadowTexture (ITexture *tex)
void	setShadowMatrices (float *m)
float *	getShadowMatrices ()
Public Member Functions inherited from Skylicht::CComponentSystem
const char *	getName ()
virtual void	reset ()
virtual void	startComponent ()
virtual void	onEnable (bool b)
virtual void	onUpdateCullingLayer (u32 mask)
void	setEnable (bool b)
bool	isEnable ()
CGameObject *	getGameObject ()
void	setEnableSerializable (bool b)
bool	isSerializable ()
void	addLinkComponent (CComponentSystem *comp)
void	removeAllLink ()
Public Member Functions inherited from Skylicht::IActivatorObject
virtual	~IActivatorObject ()
	Virtual destructor for polymorphic activator objects.

Protected Attributes
float	m_sizeX
float	m_sizeY
bool	m_needRenderShadowDepth
core::aabbox3df	m_worldBounds
Protected Attributes inherited from Skylicht::CLight
SColorf	m_color
	Diffuse color emitted by the light.
float	m_attenuation
	Attenuation factors (constant, linear, quadratic).
float	m_radius
	Radius of light. Everything within this radius will be lighted.
float	m_spotCutoff
	The angle of the spot's outer cone. Ignored for other lights.
float	m_spotInnerCutoff
float	m_spotExponent
core::vector3df	m_direction
	Direction of the light.
bool	m_castShadow
	Does the light cast shadows?
bool	m_dynamicShadow
	Does this shadow alway updates.
float	m_intensity
	Intensity of light.
u32	m_bakeBounce
	Number bounce of light on bake lighting.
ERenderLightType	m_renderType
	Light type.
u32	m_lightLayers
	The layers where the light will shine on.
u32	m_lightPriority
	Priority order of lights selected for shaders.
bool	m_needValidate
CLightCullingData *	m_cullingData
ITexture *	m_shadowTex
float *	m_shadowMatrices
Protected Attributes inherited from Skylicht::CComponentSystem
CGameObject *	m_gameObject
bool	m_enable
bool	m_serializable
std::vector< CComponentSystem * >	m_linkComponent

Additional Inherited Members
Public Types inherited from Skylicht::CLight
enum	ERenderLightType { Realtime = 0 , Baked , Mixed }
enum	ELightType { DirectionalLight = 0 , PointLight , SpotLight , AreaLight }
Static Public Member Functions inherited from Skylicht::CComponentSystem
static int	useComponent (CComponentSystem *used)
Protected Member Functions inherited from Skylicht::CComponentSystem
void	setOwner (CGameObject *obj)

Detailed Description

This object holds the parameters for area lights.

See also

CShaderLighting

Member Function Documentation

createSerializable()

virtual CObjectSerializable * Skylicht::CAreaLight::createSerializable ( )

virtual

Reimplemented from Skylicht::CLight.

endUpdate()

virtual void Skylicht::CAreaLight::endUpdate ( )

virtual

Reimplemented from Skylicht::CComponentSystem.

initComponent()

virtual void Skylicht::CAreaLight::initComponent ( )

virtual

Implements Skylicht::CComponentSystem.

loadSerializable()

virtual void Skylicht::CAreaLight::loadSerializable ( CObjectSerializable * object )

virtual

Reimplemented from Skylicht::CLight.

setRenderLightType()

virtual void Skylicht::CAreaLight::setRenderLightType ( ERenderLightType type )

inlinevirtual

Reimplemented from Skylicht::CLight.

updateComponent()

virtual void Skylicht::CAreaLight::updateComponent ( )

virtual

Implements Skylicht::CComponentSystem.

---

The documentation for this class was generated from the following file:

• Lighting/CAreaLight.h
